2E0KJH Amateur Radio and Electronics

Xonar D2X Sound Card Frequency Response

1 year ago | [YT] | 4

2E0KJH Amateur Radio and Electronics

I use a Tomahawk 450B mainboard in my PC (I say PC because it is Windows OS based, else I'd say computer).
Connecting a 3/8th to 3/8th jack cable between the speaker out and line input I made a loopback measurement using ARTA. Image below.
The bBFS is -4.5db as the onboard sound only outputs 0900mV RMS and minimum for ARTA calibration is 1000mV RMS. Still the spectrum analyser output is not bad.

The frequency response is usable also. It has a little wobble at the higher frequencies. Two images below.

Skip the Carousel

1 2 3

1 year ago | [YT] | 4

2E0KJH Amateur Radio and Electronics

Sometimes I get frustrated with myself. I setup and captured the image below. Check out the THD.
My frustration comes as for the life of me I cant remember how I did it. I've been swapping out many cables and recalibrating ARTA so many times, I've broken me.

1 year ago | [YT] | 3

2E0KJH Amateur Radio and Electronics

I think I have this correct now. I'm using ASIO drivers in ARTA after swapping out my 13 year old power supply for a new 80+ Gold PSU.
This is a 1kHz fundamental sine wave in loopback configuration (Speaker out to Aux input) of my sound card.
Sound blaster AE-9 which advertises -129db noise floor.
So far I'm very impressed, the AE-9 sounds very very good.

1 year ago | [YT] | 2

2E0KJH Amateur Radio and Electronics

Over the last month I watched this channel grow 800 subscribers from one video.
It's worrisome the lengths some would go to seemingly grow their channel.

1 year ago | [YT] | 3

2E0KJH Amateur Radio and Electronics

Hiby @ full volume 1kHz Sine

1 year ago | [YT] | 2

2E0KJH Amateur Radio and Electronics

Trying ARTA.. This is my music player output with 1kHz Sine wave.

1 year ago | [YT] | 1

2E0KJH Amateur Radio and Electronics

Latest build progress.

A few images showing the 7 inch prop build with 4K camera.

Hover tested in my lounge, flight test when the weather improves I.E when the wind drops, and it stops raining.
